Product Discontinued by Manufacturer

ATN OTS-X-F350 Thermal Imaging Monocular - 320x240, 50mm, 30Hz has been discontinued by ATN and is no longer available. Our product experts have helped us select these available replacements below.You can also explore other items in the Optics, Thermal Imaging Optics yourself to try and find the perfect replacement for you!

Product Info for ATN OTS-X-F350 Thermal Imaging Monocular - 320x240, 50mm, 30Hz

ATN OTS-X-F350 Thermal Imaging Monocular - 320x240, 50mm, 30Hz belongs to our greater selection of ATN Optics. You should check out the entire range of Thermal Imaging Optics from ATN that we present at everyday discount prices. Browse our full product selection for the gear and products you need to tackle the job at hand.

Specifications for ATN Thermal Imager OTS-X-F350 Monocular:

Sensor (microbolometer): 320 x 240
Type: Uncooled
Material: Vanadium oxide (VOx)
Image Size (output resolution): 800x600
Frame rate: 30 Hz
Video output: Analog RS-170
Lens: 50 mm
Display: Color OLED matrix, SVGA< 800x600
Thermal Sensitivity: <50mK
Spectral Response: 7-14 μm
Field of View: 7°
Eye Relief: 27 mm
Diopter Adjustment: -1.5
Optical Magnification: 4X
E-Zoom: 8X, 16X
Human Detection: 1300
Human Recognition: 500
Human Identification: 320
Vehicle Detection: 2800
Vehicle Recognition: 1100
Vehicle Identification: 700
Polarity control: White hot / Black hot / Multiple Color Modes
Start up time: <4 sec
Waterproof: Yes
Battery type: 1 x CR123A battery type
Battery Life: 2+ hrs
Weight: 1.4lb /640 gr
Dimensions: 165 x 61 x 83 mm /6.5x2.4x3.3"
Warranty: 1 year

Features of ATN OTX-X F350 Thermal Imaging Monocular:

  • Resolution 320 x 240
  • Ergonomic Design
  • Fast Imaging (30hz)
  • Compact Rugged Construction
  • Interchangable Optics
  • Variable Geometry Display
  • E-Zoom
  • Digital Brightness Control
  • Icon Based Menu System
  • Color Modes
  • Black/White Polarity
  • VOx Vanadium Oxide Detector
  • 800x600 Display
  • Video Output
  • 1 Year Warranty

Package Contents:

  • ATN F350 OTS-X Thermal Viewer TIMNOTSXF350
