ATN OTIS-10 9hz Thermal Imaging System TIMNOTIS10HZ9
Unfortunately ATN OTIS-10 9hz Thermal Imaging System TIMNOTIS10HZ9 is not listed by Shoptics.You can also explore other items in the Optics, Thermal Imaging Optics yourself to try and find the perfect replacement for you!
Product Info for ATN OTIS-10 9hz Thermal Imaging System TIMNOTIS10HZ9
ATN OTIS-10 9hz Thermal Imaging System TIMNOTIS10HZ9 belongs to our large selection of ATN Optics. Remember to take a look at the entire collection of Thermal Imaging Optics from ATN which we present at everyday discount prices. Browse our full product selection for the equipment and merchandise you need to tackle the task at hand.
Specifications for ATN Otis 10 9hz Thermal Imaging System TIMNOTIS10HZ9
Magnification:
1,8X
Objective Focal Length:
25 mm
FOV:
11 x 8
Focus Range:
from 1m to infinity
Focus Adjustment:
Manual
Exit Pupil:
14 mm
Eye Relief:
25 mm
Detector Type:
Uncooled Microbolometer
Spectral Response:
7-14 µm
Pixels:
160 x 120
Pixel Size:
30 x 30 µm
Angular Resolution, mrad:
1,2
Thermal Sensitivity:
< 0,1C
Range to Detect a Human:
475 m
Output Format:
Analog PAL / NTSC
Display:
OLED matrix
Display Format:
SVGA, 852 x 600 pxl
Color:
Monochrome
Digital ZOOM:
Fixed 2x (optional 5x)
Brightness Adjustment:
Manual
Contrast Adjustment:
Automatic
Available User Interfaces:
From outside PC through USB interface
Power Supply:
2 x 3V, 123A type
Start-Up Time:
< 3 sec
Operating Time w/one battery pack:
4 hrs
External Power Supply:
DC 6V, 500 mA
Operating Temperature Range:
from -20C to +50C
Waterproof:
Yes, up to 10m submersion
Dimensions:
118 x 81 x 47 mm
Weight (w/batteries):
0,34 kg
Features of ATN Thermal Imaging System OTIS 9hz:
High resolution digital thermal imaging
Compact, lightweight and durable housing
High Quality optics
Video and computer output
Video/Image polarity selection
Waterproof
Package Contents:
ATN Otis TIMNOTIS10HZ9 9hz Hand Held Thermal Imaging System
