Victron Energy BP-100 BatteryProtect - 100 AMP BPR000100400 Color: Blue, Voltage: 24 volts, Amperage: 100 amps, 32% Off w/ Free S&H

not yet rated review & rate
01:20
Victron Energy BP-100 BatteryProtect, 100 amps, 6-35 volts, Blue, BPR000100400
Victron Energy BP-100 BatteryProtect, 100 amps, 6-35 volts, Blue, BPR000100400
1 of 1 videos
Victron Energy - Introduction to the BatteryProtect
Victron Energy BP-100 BatteryProtect, 100 amps, 6-35 volts, Blue, BPR000100400
1 of 2 images
Victron Energy BP-100 BatteryProtect, 100 amps, 6-35 volts, Blue, BPR000100400
Victron Energy BP-100 BatteryProtect, 100 amps, 6-35 volts, Blue, BPR000100400
2 of 2 images
Victron Energy BP-100 BatteryProtect, 100 amps, 6-35 volts, Blue, BPR000100400

Tap Tap to Zoom

Color: Blue Voltage: 24 volts

Code: 3YB-BZ-BP2-BPR000100400

MPN: BPR000100400

UPC: 8719076021438

List: $97.56Save 32%
$65.99
Receive $1.32 SP Bucks

Product Info for Victron Energy BP-100 BatteryProtect - 100 AMP

Victron Energy BP-100 BatteryProtect - 100 AMP belongs to our greater variety of Victron Energy Batteries & Accessories. You should explore the complete range of Batteries & Accessories from Victron Energy which we offer at everyday affordable prices. Browse our full product choice for the equipment and products you need to tackle the job at hand.

Specifications for Victron Energy BP-100 BatteryProtect - 100 AMP:

Manufacturer: Victron Energy
Color: Blue
Voltage: 24 volts
Amperage: 100 amps

Features of Victron Energy BP-100 BatteryProtect - 100 AMP

  • 12/24V auto ranging: The BatteryProtect automatically detects system voltage
  • Programming Made Easy: The BatteryProtect can be set to engage / disengage at several different voltages. The seven segment display will indicate which setting has been chosen.
  • A Special Setting for Li-ion Batteries: In this mode the BatteryProtect can be controlled by the VE.Bus BMS. Note: the BatteryProtect can also be used as a charge interrupter in between a battery charger and a Li-ion battery. See connection diagram in the manual.
  • Ultra Low Current Consumption: This is important in case of Li-ion batteries, especially after low voltage shutdown. Please see our Li-ion battery datasheet and the VE.Bus BMS manual for more information.
  • Over Voltage Protection: To prevent damage to sensitive loads due to over voltage, the load is disconnected whenever the DC voltage exceeds 16V respectively 32V.
  • Ignition Proof: No relays but MOSFET switches, and therefore no sparks.
  • Delayed Alarm Output: The alarm output is activated if the battery voltage drops below the preset disconnect level during more than 12 seconds. Starting the engine will therefore not activate the alarm. The alarm output is a short circuit proof open collector output to the negative (minus) rail, max. current 50 mA. The alarm output is typically used to activate a buzzer, LED or relay. Delayed load disconnect and delayed reconnect The load will be disconnected 90 seconds after the alarm has been activated. If the battery voltage increases again to the connect threshold within this time period (after the engine has been started for example), the load will not be disconnected. The load will be reconnected 30 seconds after the battery voltage has increased to more than the preset reconnect voltage.

Package Contents:

  • Victron Energy BP-100 BatteryProtect - 100 AMP
